INFLATABLE LIFEJACKET – SOLAS – MODULO 150 – 160N – SAA – VACUUM PACKAGE

MODULO 150 - SMART
150,40

Description

Compact self-inflating life jacket for adults with automatic activator. SOLAS M.E.D. approved and certified, valid as on-board equipment for all vessels subject to the SOLAS M.E.D. standard., dual-compartment buoyancy chamber. Available with Single Automatic Activator (SAA).
Vacuum-packed PE packaging with tear-off opening. Closure system with quick-release buckle in acetal resin with integrated adjustment. Equipped with Buddy System.

Self-inflating life jacket designed to maximize efficiency, save space, and minimize costs.

ACTIVATION SYSTEMS
Automatic activation (self-inflating life jacket): in the event of a fall overboard, the system is submerged and automatically activates the inflation of the buoyancy chamber. It is also possible to activate the life jacket manually.
Manual activation: the system is activated by pulling the appropriate lever.
Oral inflation: to inflate the chamber, simply blow into the oral tube. present in both self-inflating and manually activated life jackets.

The COMPACT 150 - SMART self-inflating life jacket is supplied with UML-MK5, an automatic activator with a water-soluble tablet, or alternatively HAMMAR, an automatic hydrostatic activator.
All SOLAS VSG inflatable life jackets have 2 oral tubes.

TECHNICAL FEATURES
Three-dimensional X3D system buoyancy chamber with a double compartment in PA 420 PU COATED fabric with electronically controlled high-frequency welding. The system guarantees rapid and immediate rotation of the body in the water.
Vacuum-packed with a tear-off opening. Quick-release buckle. Automatic emergency light.


SPARE PARTS
VSG reset kit with 33g canister.

INSPECTION
Inspection for this inflatable life jacket is mandatory every 12 months.

The device can be customized with company writing or logos.

In compliance with the LSA Code and SOLAS standards, life jackets must be equipped with Solas signal lights.

Certification

SOLAS M.E.D.

Real Buoyancy

160N

Size

Adult

Supported Weight

43/140 kg

Chest Size

175 Cm.

Service

12 Months

C02 Cylinder

33 Gr.

Activation

SAA

Activator Type

UML/HR

02142_02132_02160_P_SMART_ID#ENG#G_compressed.pdf Scarica
02140_1_HX#_#C#SOLAS M.E.D. MODULO B 2025.pdf Scarica
  • Description

    Compact self-inflating life jacket for adults with automatic activator. SOLAS M.E.D. approved and certified, valid as on-board equipment for all vessels subject to the SOLAS M.E.D. standard., dual-compartment buoyancy chamber. Available with Single Automatic Activator (SAA).
    Vacuum-packed PE packaging with tear-off opening. Closure system with quick-release buckle in acetal resin with integrated adjustment. Equipped with Buddy System.

    Self-inflating life jacket designed to maximize efficiency, save space, and minimize costs.

    ACTIVATION SYSTEMS
    Automatic activation (self-inflating life jacket): in the event of a fall overboard, the system is submerged and automatically activates the inflation of the buoyancy chamber. It is also possible to activate the life jacket manually.
    Manual activation: the system is activated by pulling the appropriate lever.
    Oral inflation: to inflate the chamber, simply blow into the oral tube. present in both self-inflating and manually activated life jackets.

    The COMPACT 150 - SMART self-inflating life jacket is supplied with UML-MK5, an automatic activator with a water-soluble tablet, or alternatively HAMMAR, an automatic hydrostatic activator.
    All SOLAS VSG inflatable life jackets have 2 oral tubes.

    TECHNICAL FEATURES
    Three-dimensional X3D system buoyancy chamber with a double compartment in PA 420 PU COATED fabric with electronically controlled high-frequency welding. The system guarantees rapid and immediate rotation of the body in the water.
    Vacuum-packed with a tear-off opening. Quick-release buckle. Automatic emergency light.


    SPARE PARTS
    VSG reset kit with 33g canister.

    INSPECTION
    Inspection for this inflatable life jacket is mandatory every 12 months.

    The device can be customized with company writing or logos.

    In compliance with the LSA Code and SOLAS standards, life jackets must be equipped with Solas signal lights.

  • TYPES OF ACTIVATION

    Automatic activation

    Automatic: in the event of a fall into the sea, the system is submerged and activates autonomously, within 5 second, the inflation of the buoyancy chamber. Automatic activation is possible with the UML MK5 salt activator, through the dissolution of a water-soluble tablet, or with the hydrostatic activator Hammar MA1 through the pressure generated by immersion in water for at least 10 cm.

    Manual activation

    The system is activated through the draft of the appropriate lever. It comes with the manual activator UML MICROMANUAL and it will activate exclusively by hand.

TYPES OF ACTIVATION

Automatic activation

Automatic: in the event of a fall into the sea, the system is submerged and activates autonomously, within 5 second, the inflation of the buoyancy chamber. Automatic activation is possible with the UML MK5 salt activator, through the dissolution of a water-soluble tablet, or with the hydrostatic activator Hammar MA1 through the pressure generated by immersion in water for at least 10 cm.

Manual activation

The system is activated through the draft of the appropriate lever. It comes with the manual activator UML MICROMANUAL and it will activate exclusively by hand.
